Description
Product Description
Three Tier Orbital Shakers consist of heavy duty mild steel fabricated housing comprising of a brushless induction motor and variable frequency drive, these shakers has a universal platform with a provision of ?ask holders for various ?ask capacities. These orbital shakers are available in 7 different models based on number of ?ask holding capacity and speed.
- Universal Platform to accommodate for conical ?asks , round bottom flask, volumetric flask and test tube rack.
- Adjustable levelling Jack
- 5 programs memory
- Forward and backward rotation programs
- Auto restart at set rpm when power resume.
- 365 days Continuous operation
- Maintenance free Brushless Induction Motor
- Permanently lubricated bearing for noise less operation
- Eccentric counter balanced drive mechanism for uniform mixing
- Continuous operation
- Variable frequency drive (VFD)
Product Information
| Technical Specifications | ||||
| CAT. No. | LOS-90D | LOS-120D | LOS-120T | LOS-150T |
| Number of Platform | 2 | 2 | 3 | 3 |
| Control | Programmable Logic Control (PLC) | |||
| Display | 4.3” HMI with Colour Display and touch screen | |||
| Amplitude (mm) | Ø50 | |||
| Accuracy (rpm) | ± 5 | |||
| Timer ( hrs) | 1-999 | |||
| Speed (rpm) | 30 – 250 | 30 – 200 | ||
| MOC of Shaking platform | Aluminium powder coated | |||
| Tray size (mm) | 900×620 | 1280×620 | 1640×1040 | |
| Outer dimension (mm) | 920x670x700 | 1390x760x800 | 1390x760x1180 | 1640x1040x1180 |
| Platform | Universal | |||
| Weight (kg) | 110 | 150 | 200 | 350 |
| Input Voltage | 230 VAC / 50 Hz | |||
| Construction | Mild Steel powder coated | |||
