Product Description
• Independent LCD display for speed and time
• Compact footprint
•  Provides smooth and uniform shaking
• 7.5 kg with platform and  speed range 100-500 rpm
•  Continuous or timer operation mode
• Maintenance- free brushless DC motor
• Over speed detection and protection
• Wide range of optional platform for flasks, and other popular vessels
•  Remote function provides PC control and data transmission
•  Free software for PC control & data logging
Product Information
| Cat.No. | EDOS-500 |
| Amplitude | 10mm |
| Speed range | 100-500rpm |
| Timer display | LCD |
| Data connector | RS232 |
| Motor type | Brushless DC motor |
| Motor rating output | 15W |
| Voltage | 100-240V |
| Dimension[W×D×H] | 370×420×100mm |
| Weight | 12kg |
| Permissible ambient humidity | 80% RH |
| Motion type | Orbital Shaker |
| Speed display | LCD |
| Time settings range | 1min-19h59min |
| Max. load capacity | 7.5kg |
| Motor rating input | 28W |
| Power | 30W |
| Frequency | 50/60Hz |
| Work plate Dimension | 320×320mm |
| Permissible ambient temperature | 5-40? |
| Protection class | IP21 |
