Description
Product Description
Digital Cameras with Next Generation CMOS Sensor:
The plug and play ESAW IS Series Cameras produce high quality images making it a great choice for education, pathology and research applications. Available in 3,5,10 & 14 Megapixels.
Powerful, user-friendly IS Series software comes with tools for:
Image Enhancement(hue,saturation,contrast,etc)
• 2D Measurement including calibration
• Auto-exposure and single click white balance
• Image Stitching
• extended depth of focus
• Capture images, videos and time lapse images
• Compatible with Windows, Mac OS and Linux
• C/C++, C#, DirectShow, Twain Control API
Product Information
| Camera MODEL | Scopecam IS-3 | Scopecam IS-5 | Scopecam IS-10 | Scopecam IS-14 |
| MODEL NO | IS-300 | IS-500 | IS-1000 | IS-1400 |
| Camera Casing | Metal Alloy | |||
| Camera Dimension | 60X60 X40 MM | |||
| Image Sensor | CMOS 3.1MP | CMOS 5.1MP | CMOS 10MP | CMOS 14MP |
| Sensor size | 1/2” | 1/2.5” | 1/2.3” | 1/2.3” |
| Pixel Size | 3.2 X3.2 micron | 2.2 X2.2 micron | 1.67 X 1.67 micron | 1.4 x 1.4 microns |
| Resolution (Max) | 2048X1536 Pixels | 2592X1944 Pixels | 3584X2748 Pixels | 4096X3288 Pixels |
| Frame Rate | 8 @ 2048X1536 | 5@2592X1944 | 1.9@3584X2748 | 1.8@4096X3288 |
| 22 @1024×768 | 18@1280X960 | 8@1792X1374 | 10@2048X1644 | |
| 43 @ 680X510 | 60@640X480 | 27@896×684 | 27@1024X822 | |
| Dynamic Range | 61dB | 66.5dB | 65.2dB | 65.3dB |
| Signal/Noise Ratio | 43dB | 40.5dB | 34.0dB | 35.5dB |
| Bining | 2×2, 3×3 | 2X2, 4X4 | 2X2 ,4X4 | 2X2 ,4X4 |
| Exposure Time | 0.24ms to 2000ms | 0.29ms to 2000ms | 0.4ms to 2000ms | 0.4ms to 2000ms |
| Spectral Range | 380 -650nm with IR filter | |||
| Software | ||||
| Operating System | Win XP/Vista/7/8/10 (32,64bit) | |||
| Software | ESAW Images analysis | |||
| Image Format | JPG/TIF/BMP/PNG | |||
| Electronic Interface | ||||
| PC/Laptop | USB-2 for Win & Mac | |||
| Power Supply | 5V DC Via USB-2 | |||
| Operating temp | -10 deg.C to + 50deg.C | |||
| Operating Humidity | 30 to RH | |||
| Computer | ||||
| CPU | Core-2,i3 ->2GB RAM | |||
| Other requirments | C Mount/Eye piece Mount+Computer{Laptop+Software MagVision | |||
