XD Binocular Microscope

Description

Product Description

New generation of infinity color corrected optical systems and professional plan semi-apochromatic fluorescence objectives, present you sharp and br- ight fluorescence image.
Professional fluorescence filter system, imported optical material and broa- dband multilayer coating, high transmissivity, mould proof, heat insulation a- nd safety protection system, OSRAM brand mercury lam digital power-supply control.
Swallow tail slide switch easy to change filter cubes, three paths for fluores- cence and one for bright field, four filter cubes can be mounted.
Scientific research class cold CCD, high resolution, fast transmission. Intell- igence Chinese fluorescence image processing software, meets any requ- est of the most professional picture processing.
6V/30W transmission illuminator, various performances, bright-field, dark-fi- led, phase contrast, polarization observations.

Product Information

Optical system	Infinity color corrected optical system
Eyepiece	PL10X /22,PL15X16 High eye -point wide field plan eyepiece
Objective	Long working distance infinity plan achromatic /phase contrast /fluorescent objective ;long working
Viewing head	45°inclined gemel binocular /trinocular viewing head (erect image ),splitting ratio for binocular tr
Nosepiece	Revolving quintuple nosepiece
Stage &related	Fixed stage ,size :250X160mm;movable rule ,travel range :120x78mm;extension plate ;slides holder ;
accessories	Terasaki holder ;glass plate ;metal plate (kidney slot );$35mmPetri dish holder .
Body	Coaxial focus system with tension adjustment ;coarse adjustment range :9mm,fine adjustment precision, XDRFA reflected illuminator (Koehler illumination ),with iris field diaphragm (centering adjustable U -LH100HG mercury lamp house ,filament center and focal distance adjustable .With mirror ,mirror center and focal distance adjustable .
Reflected fluorescence	U1 -RFLT100 digital power control box ,wide voltage range 90-245VAC
illumination	Imported OSRAM 100WDC mercury bulb
system	Centered objective for mercury bulb Band -pass fluorescent filter (integrated ):B /G /V /UV 30ND25attenuation plate Critical illumination with iris aperture diaphragm ;6V30Whalogen bulb ,pre -centered ,intensity adjust
Transmitted illumination system	Koehler illumination with iris aperture and field diaphragm ,6V30Whalogen bulb ,pre -centered ,intenLBD color temperature change filter /IF550 green interference filter $30mmcentering telescope
Accessories	XDSL center -adjustable phase contrast plug -board for 10X-40XXDSL1 center -adjustable phase contras
Camera adapter	1X&1/2X&1/3XC -mount ;Photo tube 3.2Xphoto eyepiece (with PK mount );Relay lens with C -mount
