Vertical Autoclave

Description

Product Description

Vertical autoclaves are also known as top loading sterilizers that come in cylindrical shape. These are widely used in hospitals, Operation Theater (OT), microbiology laboratory for sterilization of various medial and cultures. The working of vertical autoclave is simple to understand; to open, a radial locking mechanism is fitted at top of the lid; a foot lever (pedal) is attached at the bottom. User has to press the pedal and lift the lid.

We make various types of vertical autoclave machines as per budget and intended use. Economy models come with powder coated MS exterior and stainless steel interior. Our Deluxe models are double walled vertical autoclaves and made with inner and exterior both of stainless steel; while the Triple Walled models have another chamber and all three walls are made of thick gauge of stainless steel sheets.

Stainless steel interior
Digital temperature indicator
Digital temperature Controller
Up to 121°C temperature range
Silicone rubber gasket
Pedal for lid opening
Water inlet & outlet valves
Water level indicator

Product Information

Model No.	VA-22	VA-35	VA-50	VA-75	VA-95	VA-120	VA-180	VA-220
Dimensions In MM	250 mm x 450 mm	300 mm x 500 mm	350 mm x 550 mm	400 mm x 600 mm	450 mm x 600 mm	450 mm x 750 mm	550 mm x 750 mm	600 mm x 750 mm
Volume	22 Ltrs.	35 Ltrs.	50 Ltrs.	75 Ltrs.	95 Ltrs.	120 Ltrs.	180 Ltrs.	220 Ltrs.
Inner chamber	SS 304 with full argon welding
External chamber	SS 304
Finishing	Mirror finished inner and external surface
Insulation	Glass wool
Chamber condensate line	Fitted with steam trap and check valve
Working temperature	121°C
Working pressure	15 to 20 psi
Sensor	PT100
Radial locking system	Chrome plated MS
Power supply	440 Volts 50Hz, Three Phase
Tray	Perforated tray made of SS 304
Optional accessories	Mechanical timer 0-60minutes, Sterilization drums, Digital temperature control
Construction	ECONOMY WALLED		DOUBLE WALLED		TRIPLE WALLED
LID	POLISHED MS		SS 304		SS 304
NO. OF WALLS	TWO		TWO		THREE
