Vertical Autoclave Wing Nut Locking

Description

Product Description

These wing nut vertical autoclave also feature microprocessor based controller, which displays temperature, pressure and time of sterilization process. User can set their application specific sterilization parameters. The construction is sturdy and made of complete stainless steel 304 sheets fabricated with CNC machines so that you enjoy the beautiful designed along with reliable and sterilization process. These wing nut autoclave are available in different volumes such as 35 Liters, 50 Liters, 75, 100, 120 and 150 Liters. These machines are suitable for hospitals, laboratory and pharmaceutical microbiology laboratory for decontamination etc.

Wing nut locking mechanism
Self-inflating silicone rubber seal
Microprocessor based controller
Precise sterilization operation
All stainless steel 304 construction
Automatic steam release after sterilization
Low water level protection
Over temperature protection
Over pressure safety protection

Product Information

Model No.	WNLA-35	WNLA-50	WNLA-75	WNLA-100	WNLA-120	WNLA-150
Dimensions In MM	318 x 450 mm	340 x 550 mm	400 x 600 mm	440 x 650 mm	480 x 660 mm	510 x 740 mm
Volume	35 Ltrs.	50 Ltrs.	75 Ltrs.	100 Ltrs.	120 Ltrs.	150 Ltrs.
Temperature	105°C to 134°C
Working pressure	0.22 Mpa
Timer	0-99 minutes
Construction	Fully stainless steel 304
Display	LED display of Temperature, pressure & time
Controller	Softy key pad controller
Power supply	220 Volts 50Hz
Mounting	Caster wheels
