The Ultimate Trainer Microscope is designed for educational and research facilities looking for table-top magnification systems that can provide a long working distance, bright and homogenous LED illumination, and super resolution images all in a compact form factor with fluid maneuverability. Our MaxLite™ coated apochromatic magnichanger promises high color fidelity in three color wavelengths. A well designed arm enables a lower center of gravity, ensuring a well balanced and vibration free microscope that won’t monopolize your workstation.
Product Information
Microscope carriers
120° carrier
Eyepiece
WF 10X/18mm with retractable eye guards, diopter adjustment ± 5mm with diopter lock; optional: WF 12.5X/18mm
Objective
f-250 mm with fine focus (standard); Options: NuVar with focal length adjustment f-300-400 mm, f-200-400 mm; f-300 mm or f-400 mm with fine focus; f-200 mm fixed objective; objective lens protector.
Light Source
50W LED; 100,000+ Lux
Built-in-Filters
Green & Yellow
Binocular Tube
0-210° tiltable ergonomic head
Vertical Movement of arm
± 250 mm, power saving feature with light cut-off in park position
Apochromatic Magnichanger
5 step: 0.4X, 0.6X, 1.0X, 1.6X, 2.5X
Package Contents
Tools for securing table mount
Mounting Options
Table mount only
Accessories (Optional)
Beam splitters (straight/inclined)
Rotoplate and/or extender
Proline range of camera/video adapters
NuVar variable working distance objective
Spacers and extender arms
