Temperature Humidity Test Chamber

Material of construction: Our temperature and humidity chambers are made with completely corrosion resistant material. Inner chamber is made with high grade stainless steel (304 or 316); while, exterior is made with corrosion resistant powder coated GI sheet. The gap between these two walls is filled with thick layer of high density PUF insulation.

Door sealing: We use only environmentally safe Silicone gasket which is high temperature resistance, aging resistance and moreover feature excellent sealing capability. Low temperature chamber chambers are fitted with double sealing.

Controller: For greater accuracy and reliability, we use only PLC based HMI controller. This controller features color touch screen, graphical display and data logging. User can set temperature and humidity range with pro?ling. A USB port is given to transfer data into pen drive. We also provide ETHERNET connectivity if required.

Air circulation: Proper air circulation is mandatory requirement for any humidity test chamber; we use heavy duty motor driven blowers or stainless steel axial ?ow fans for uniform and rapid air distribution across the chamber.

Cooling: For efficient cooling temperature, we use hermetically sealed CFC free compressors of reputed brands in the market including EMERSON.

Heating: Heating inside the chamber is created through energy efficient SS finned air heaters.

Humidity System: In order to generate humidity inside the chamber, we equip our test chambers with stainless steel water reservoir tank fitted with immersion heaters for vaporization. To keep humidity system safe from low water, we also fit low water cut-off device.
