Solar Panel Test Chamber

Description

Product Description

Thermal Cycle Test: Thermal cycle test is performed according to IEC 61215:2005 standard to test ability of PV module to withstand effects of temperature stress. This test is performed between temperature 85°C and -40°C with fast changing rate. Number of cycles is run 50 or 200 times.

Humidity Freeze Test: Humidity freeze test is performed to determine ability of PV modules withstand against high temperature and humidity conditions followed by sub-zero temperature. In this this 10 cycles are run between 85°C with 85% relative humidity and negative temperature -40°C.

Damp Heat Test: Damp heat test is performed to test effects of long exposure of humidity penetration and high temperature. In this test is performed by applying 85°C ±2°C temperature with relative humidity of 85% for uninterrupted cycle of 1000 hours.

Product Information

TEMPERATURE RANGE	-60°C to 100°C
TEMPERATURE FLUCTUATION	±0.5°C
TEMPERATURE DEVIATION	±2.0°C
HUMIDITY RANGE	20%to 98%RH
HUMIDITY DEVIATION	±2.5%RH
TEMPERATURE CHANGE RATE	1to3.4°C /Min
TEMPERATURE SENSOR	Class A Pt100
HUMIDITY SENSOR	Dry and wet bulb sensor
AIR CIRCULATION	Centrifugal blower system
CONTROLLER	color LCD touch screen controller ,100programs with 100segments,Temperature ,Humidity and Time settings ,In -built data recording
PANEL SIZE	1x 2meter
PANEL CAPACITY	4/6/8/10/12panels
TEST PARAMETER	Thermal Cycle Test :50or 200cycles from -40°C to +85°C, Humidity Freeze Test :10cycles from +85°C ,85%RH to -40°C , Damp Heat Test :1000hours at 85C,85%RH
COOLING SYSTEM	Mechanical compression refrigeration system
REFRIGERATING UNIT	French TECUMSEH compressor
REFRIGERANT	R404A ,R23
HEATING ELEMENT	Nichrome heater
DATA RECORDING	Ethernet connection ,PC Link ,USB
EXTERIOR MATERIAL	Powder coated steel sheet
INTERIOR MATERIAL	Stainless steel 304
WATER SUPPLY SYSTEM	Automatic water supply
HUMIDITY SYSTEM	Stainless steel surface evaporation humidity system
DEHUMIDIFICATION	Evaporator
