Product Description
Temperature cycling chambers are ideal for test applications that require quick change in temperature ramp rate such as 1°C and 4°C per minute or as required. In such applications ramp rate of hot and cold temperatures is important and also mandatory in some standards such as IEC, JESD, SAE and IPC. These chambers are widely used for testing PCB, electronic components, semiconductor devices, battery, various electronic devices like mobile phones, LED and LCD TV and monitor etc.
Temperature: Standard temperature range of a hot and cold chamber is -70°C to 180°C. We also provide customized range lower than this such as -20° to 70°C and -40°C to 100°C etc. Standard ramp rate / temperature change rate is 15°C.
Control System:Â We equipment our temperature cycling chambers with PLC based HMI controller, which features color touch screen, temperature control settings, ramp and soak time etc. Various types of errors in machine are also seen on the screen. It also features data monitoring and storage, user can save readings in pen drive through USB interface.
Construction:Â Standard chambers are made with stainless steel inner chamber; while exterior cabinet is made of powder coated GI sheet. The steel frame is nicely welded and firmly jointed to ensure you a rugged machine. High density PUF insulation is filled in the gap between inner and external walls. Heavy duty caster wheels are fitted at bottom for easy mobility of the temperature cycling chamber.
Door:Â The door is also insulated and fitted with imported latch. A silicone gasket is fitted on the door for excellent sealing. A frost free observation glass window is also provided on the door.
Heater:Â Only branded SS tubular air heaters are used in our hot and cold chambers to generate heat. These heaters provide rapid heating with long service life.
Refrigeration:Â For low and freezing temperature, we use only imported refrigeration system which is CFC free; usually we use only EMERSON make compressor which offers trouble free cooling for years.
Product Information
| Model No. | TCC-160 | TCC-216 | TCC-300 | TCC-400 | TCC-600 | TCC-1000 |
| Dimensions In MM | 800 x 400 x 500 | 600 x 600 x 600 | 500 x 500 x 1200 | 600 x 600 x 1200 | 700 x 700 x 1200 | 1000 x 1000 x 1000 |
| Capacity | 160 Ltrs. | 216 Ltrs. | 300 Ltrs. | 400 Ltrs. | 600 Ltrs. | 1000 Ltrs. |
| TEMPERATURE RANGE | -70°C to 180°C Or as required | |||||
| RAMP RATE /TEMP .CYCLING | 10°C 15°C /minute or as required | |||||
| INNER CHAMBER | Stainless steel 304 | |||||
| EXTERNAL CABINET | Powder coated GI sheet | |||||
| DOOR | Insulated door with clamp ,Heated glass window ,Silicone gasket for sealing | |||||
| CONTROLLER | PLC based HMI controller ,Color touch screen ,Display of SV &PV In -built data logging ,Trend graph display | |||||
| TRAYS | Steel wire mesh cable trays | |||||
| SENSOR | Pt100 | |||||
| HEATER | SS tubular air heater | |||||
| REFRIGERATION SYSTEM | CFC free hermetically sealed compressor | |||||
| AIR CIRCULATION | Motor driven blower | |||||
| SAFETY FEATURES | Temperature variation alarm ,Over temperature protection Delay timer for compressor | |||||
| POWER SUPPLY | 220/440Volts 50Hz 30/50mm port hole ,Ethernet connection ,Strip chart recorder | |||||
| ACCESSORIES | Complete SS construction ,Humidity system | |||||
