Product Description
The stereoscopic microscope provides 18:1 zoom ratio
- Provide high resolution and 18K zoom ratio, with 7.5x-135x zoom range under IOX eyepiece to meet your usage needs from sample overview to detailed observation.
- The high NA objective Use the newly developed high NA IX stereoscopic objective. The NA up to 0.15.
- Apochromatic optical system Using apochromatic optical system not only in the bright ?eld, even in the ?uorescence ?eld, to ensure uniform ?eld brightness at the lowest ratio and the image is clear and reliable at high ratio.
LARGE OPERATING SPACE
- 1x objective can provide a working distance of 60mm to facilitate you to place and move samples. NA up to 0.15 can provide you with clarity for further study. Large ?eld Df view allows you to see a wider and more comprehensive sample area.
TRINOCULAR VIEWING HEAD AND DIGITAL IMAGING
- The viewing head is comfortable to use :Â The viewing head ane the visibility is adjustable. So you can observe in the most natural and comfortable position. This can minimize the visual fatigue caused by long time observation.
- Digital viewing:Â Standard trinocular viewing head can be connected with camera to realize video real-time observation and Images taken. And equipped with special image analysis software to meet your various imaging and analysis in scientific research.
Product Information
| Device | Technical Specifications |
| Optical system | Parallel light (zoom type) apochromatic optical system |
| Manual | Zoom |
| Zoom ratio | 20:01 |
| Zoom range | 0.75-13.5x |
| Objective lens NA, WD | PLAN APO 1x 0.15, 60 mm |
| Total magnification (1x large object, 10x eyepiece) | 7.5-135x |
| Eyepiece (FOV mm) | 10x (23) |
| Lens tube (eye-piece/port) | Trinocular 20 fixed inclination lens barrel (100/0, 0/100) |
| Focusing device (stroke) | 60 + 99 mm |
| Adapter | DC 12V, 2A |
| Base | LED three-dimensional lighting base (OIC built-in illuminator) |
| Observation method | Bright field, oblique illumination |
| Observation methods with optional accessories | Fluorescence, simple polarized light, dark field |
| Weight (approx.) | 10.5 kg |
| Power consumption (approx.) | 10 W |
| Operating environment | Indoor use |
| Altitude: up to 2000 meters | |
| Ambient temperature: 5°C~40°C (41°F~109°F) | |
| Maximum relative humidity: relative humidity at a temperature of 31°C (88°F) | |
| The relative humidity is 70% when the temperature is 34°C | |
| The relative humidity is 60% when the temperature is 37°C | |
| The relative humidity is 50% when the temperature is 40° C | |
| Pollution degree: Level 2 | |
| Atmospheric pressure: 80kPa~106kPa | |
| Overvoltage category: Class II |
