Product Description
Key Features:
- 20mm Wide Field Eyepieces
- Swinging Adjustment of View
- Ring Illumination Light
- Auxiliary Lens
- Trinocular with Camera Option
- LED Incident and Transmittal Light (Standard)
- Integrated Control for LED Light
- Black/White Plate
Product Information
| OPTICAL SYSTEM | GREENOUGH Stereoscopic |
| Objective | Plan Achromatic Objective 1x |
| Viewing Body | Integated Binocular, 20 degree |
| EYEPIECE | Widefield 10x/22mm (Interchangeable), 53- 75mm IPD |
| ZOOM RATIO | 01:10 |
| ZOOM OBJECTIVE | 0.7x-4.5x |
| MAGNIFICATION RANGE | 8x to 80x Continuous (with 10x eyepiece) |
| WORKING DISTANCE | 78mm. |
| EYE GUARDS | Rubber, Retractable |
| OBJECT FIELD DIAMETER | 6.6 to 28.5 mm |
| ILLUMINATION CONTROL | Incident / Transmitted (“Oblique” Settings) / Combined illustration control buttons with rheostat dial for light intensity control |
| INCIDENT LIGHT METHOD | LED 3.3W with intensity control. |
| TRANSMITTED LIGHT | 3.3 W LED super bright glow screen, low heat emission |
| LED SERVICE LIFE | Approx 6,000 hours |
| LIGHT QUALITY | Homogeneous daylight (6500°K), free of UV and IR emissions |
