Surgical Ultimate Motorised Microscope

Apochromatic Magnichanger

Motorized 5-steps: 0.4X, 0.6X, 1.0X, 1.6X, 2.5X; tilt-able with auto lock

Eyepiece

Standard: WF 10X/18mm with eye guards Optional: WF 12.5X/18mm with eye guards All eyepieces have diopter adjustment ± 5 mm and diopter lock

Vertical Movement of arm

±300 mm

Microscope carriers

10 function wired foot switch for xyz, magchanger & intensity control. Z-axis 40 mm, motorized noise free, 50 X 50 mm XY with auto reset

Binocular Tube

0-210° Binocular tiltable head

Arm

Swivel 470 mm, Suspension 1000 mm

Built-in-Filters

Daylight, blue barrier (yellow filter), fluorescein excitation (cobalt blue), vascular identification (green filter), anti-glare (two spot diaphragm) and retinal protection interoperative viewing modes

Stand

Robust “Pyramid” stand for counter balancing, vibration-free base with four lockable castors

Light Source

UV & IR free 50W LED

Objective

Standard: f=200 mm, Optional: f=175 mm

Accessories (Optional)

• Assistant binocular attachment, Proline range of camera adapters, Smart phone adapters
