Product Description
Plant Growth Chamber is a closed cabinet having provision of three side lights, humidity and temperature. It is widely used in in plant biology, soil science and agriculture research and growth of rice and Arabidopsis etc. The purpose of using a plant growth chamber or tissue culture growth chamber is to create arti?cial environment using combination of temperature, humidity and light at various ranges.
- Accuracy of temperature, humidity & light
- Made according to plant height
- Digital control panel
- Digital light timer
- Height adjustable shelves
- Durable construction
Product Information
| Model No. | PGC-150 | PGC-250 | PGC-350 | PGC-600 | PGC-800 | PGC-1000 |
| Dimensions In MM | 800 x 500 x 380 | 550 x 450 x 1000 | 550 x 550 x 1200 | 800 x 600 x 1250 | 1120 x 600 x 1200 | 1150 x 670 x 1300 |
| Capacity | 150 Ltrs. | 250 Ltrs. | 350 Ltrs. | 600 Ltrs. | 800 Ltrs. | 1000 Ltrs. |
| TEMPERATURE RANGE | Lights Off :5°C to 60°C ,Light ON :10°C to 60°C | |||||
| TEMPERATURE CONTROLLER | Digital PID controller with SV &PV values | |||||
| TEMPERATURE ACCURACY | +1% | |||||
| HUMIDITY RANGE | 50%to 90% | |||||
| HUMIDITY CONTROLLER | Digital PID controller with SV &PV values | |||||
| HUMIDITY ACCURACY | ±3% | |||||
| ILLUMINATION | 3sides illumination with detachable LED lights (10000LUX or 23000LUX ) | |||||
| LIGHT TIMER | 24x7weekly digital timer | |||||
| AIR CIRCULATION | Forced air circulation through axial fans | |||||
| CONSTRUCTION | Double walled | |||||
| EXTERIOR | Powder coated steel | |||||
| INTERIOR | Made of Stainless steel 304with silicon gasket | |||||
| OUTER DOOR | Insulated solid door with lock &key and magnetic gasket | |||||
| INNER DOOR | Toughened Glass door to view samples | |||||
| INSULATION | 3inch thick PUF insulation | |||||
| SHELVES | Stainless steel or chrome plated (Height adjustable ) | |||||
| HEATING | Tubular air heaters | |||||
| COMPRESSOR | EMERSON Copeland brand compressor CFC free | |||||
| HUMIDITY SYSTEM | SS boiler tank with immersion heater and automatic water replenishment by external tank | |||||
| SAFETY | Audio /visual alarm for temperature deviation | |||||
| POWER SUPPLY | 220Volts /50Hz | |||||
| ACCESSORIES | Exterior made of stainless steel 304/316,White painted steel inner walls ,Door open alarm ,Plant growth racks ,UV lamp ,PLC with HMI interface ,Data logger with USB interface ,Password protection for controller ,Caster wheels | |||||
