Product Description
1.Make Reasonable improvement on basis of scientific research microscope. More suitable for laboratory observation of cells.
2.Adopt long life LED light source and infinity optical system, easy to obtain high-definition and high contrast wide viewing images.
3.The body is compact and stable, and the operation buttons are well arranged, the cells can be observed, sampled and processed in the super clean bench freely.
4.Using 3 different color filter, it widely enlarges selectivity for dye. LED illumination with large intensity and even brightness provides support for high quality fluorescence observation.
5.With standard camera port, ESAW camera and image processing software, providing low noise, high sensitivity and resolution imageity and resolution image
Product Information
| Optical System | NIS Infinite Optical System (F200 ) |
| Observation method | Brightfield ,Phase Contrast ,Hoffman phase Contrast .Emboss Contrast |
| Tramsmitted illumination | 3WS -LED |
| Viewing Head | Seidentopf Viewing Head ,Inclined at 45°,Interpupillary 48-75mmAdditional camera port eyepiece /port 100/0 : 0/100 |
| Eyepiece (F.O.V ) | SW10x (22)WF15x (16)WF20x (12) |
| Focusing | Coaxial coarse and fine adjustment ,the function of coarse tightness adjustment , Fine Division 1um ,Fine stroke 0.2mmper rotation ,Coarse stroke 37.5mmper rotation .Up 7mm.down1.5mm . |
| Condenser | Condenser NA 0.3,WD 75mm,without Condenser WD 187mm |
| Stage | Stage 170(X )X 250(Y )mm, Attachable Mechanical Stage :128(X )XÂ Â Â Â Â Â Â Â 80(Y ),Accepts 5types of micro -testplate ,well clamper and stage clip . |
| Phase System | Condener with 4xPhase Annulus Plate 10x,20,40xUniversal Phase Annulus Plate |
| Hoffman Phase | .10x.20x40xHoffman Condenser Special objective |
| Relief 3DContrast | Condenser and Eyepiece with Emboss Contrast 10%,20%,40%,Universal Emboss contrast slide |
| Dimensions | 244(W )x543 (D )x526 (H )mm |
| Video Adapter | 1x.0.5*,C Mount |
| Accessories | ECO (No operator ,turn off the light source automatically in 15minutes );Heating Stage |
