Product

Digital Ultrasonic Cleaner

Description

Product Description

Digital Ultrasonic cleaning is based on the cavitation effect caused by high frequency ultrasonic wave vibration signal in the fluid. Microscopic bubbles are formed, and they implode violently causing the cavitation which create an intense scrubbing action on the surface of the item being cleaned. The bubbles are small enough to penetrate microscopic crevices, cleaning them thoroughly and consistently.

Ultrasonic cleaning is extremely effective at removing dirt and grime which would normally require tedious manual cleaning by hand. It has been used to clean a wide variety of instruments and mechanical parts such as carburetors, returning them to almost “like new” condition without damage to delicate parts.

Salient Features

  • Inner Tank & Outer body made of Stainless Steel
  • Digital RED LED display
  • Temperature with timer function
  • Ceramic heaters provides improved heating effect
  • Drainage and cool fan available in 6L to 25L
  • Overheat protector, Cooling fan
  • Moisture-proof PCB
  • User friendly
  • High-performance transducers.
Product Information
MODEL EDUC-3 EDUC-5 EDUC-10 EDUC-15 EDUC-25
Tank Capacity (Approx.) 2.5L 5L 8L 11L 24L
Tank Size (mm) 240x140x100 300x155x150 300x240x150 330x300x150 500x300x200
Overall Size (mm) 270x170x240 330x180x310 330x270x310 360x330x310 550x330x360
Ultrasonic Power 100W 150W 200W 300W 500W
Heating power 100W 300W 300W 400W 500W
Tank Drain NA Drain Valve
Time Setting 1-99 min.
Heating Temp. 0-80°C
Display Digital RED LED
Frequency 40kHz
Lid Material SS 304
Inner Tank Material SS 304
Outer Tank Material SS 201
Power Supply AC 220V / 50 Hz
Weight (approx.) 4 kg 8 kg 10 kg 13 kg 18 kg



STANDARD ACCESSORIES :

  • Main Instrument
  • Digital RED LED display
  • Lid
  • Power cord
  • Basket
  • Instruction Manual
