Product Description
This newly designed ESAWÂ microscope model features improved optics and a sleek, ergonomic design. This series of microscopes features high-quality optical and mechanical components that offer reliable functionality for years of use. The illumination system (CE approved with universal power supply) is variable and available in two formats, halogen and LED making it cordless with the supplied rechargeable battery.
These are configured with a Wide Field 10x eyepiece, quadruple nosepiece with Semi-Plan Objectives, mechanical stage and sturdy stand with extended base for enhanced stability and comfort. There are a variety of options and accessories available including binocular & trinocular bodies.
Product Information
| MAIN BODY | HIGHLY RIGID, VIBRATION FREE SINGLE PIECE (BASE, COLUMN & ARM) ALUMINUM ALLOY CASTING, WITH TRANSMITTED LIGHT,POWER SUPPLY & BRIGHTNESS CONTROL INTEGRATED IN THE BASE. THE FRAME IS STABLE,STRONG, BIG & EASY TO CARRY. PUREWHITE BODY WITH BLUE ON THE BOTH SIDES, IS FRESH AND VIVID DESIGN. |
| OPTICAL SYSTEM | INFINITY COLOR CORRECTED OPTICAL SYSTEM |
| VIEWING | 30° INCLINED SIEDENTOPF BINOCULAR HEAD, INTERPUPILLARY DISTANCE: 50-75MM, +5 DIOPTER ADJUSTABLE, 360° ROTATABLE |
| OBJECTIVE | SEMI PLAN ANTI FUNGUS OBJECTIVE 4X, 10X, |
| FOCUSING | 40X (S) AND 100X OIL, (S) |
| LIGHT SOURCE | LIGHT SOURCE: ILLUMINATION SYSTEM LED 3.5W 3V WITH INTENSITY CONTROL REGULATOR, UNIVERSAL POWER SUPPLY 110V – 240V, CE APPROVED. |
| EYE -PIECES | WIDE FIELD EYEPIECE 10X, FOV 18MM WITH DIOPTER SETTING |
| FOCUSING MOVEMENT | COAXIAL COARSE AND FINE FOCUSSING MECHANISM, WITH MAXIMUM HEIGHT LOCKABLE CLIP. ERGONOMICALLY DESIGNED FOR EASY GRIP. FOCUSSING RANG-30MM |
| STAGE | GRADUATED DOUBLE LAYER MECHANICAL RECTANGULAR STAGE, SIZE 140 X 140MM WITH CROSS TRAVEL 90MM (X) X 65MM (Y) ON BALL BEARING WITH CO-AXIAL CONTROLS. |
| NOSEPIECE | BALL BEARING LOADED, INWARD QUADRUPLE NOSEPIECE WITH PRECISE, POSITIVE STOPS FOR CENTERED ALIGNMENT OF OBJECTIVES. |
| MAGNIFICATION SETTING | 8 MAGNIFICATION SETTING: 40X, 60X, 100X, 150X, 400X, 600X, 1000X & 1500X |
| CONDENSER | CENTERABLE ABBE CONDENSER, NA 1.25 WITH ASPHERIC LENS. |
| PACKING & ACCESSORIES | CARRYING CASE: STYROFOAM PACKING & OUTER CORRUGATED BOX SUPPLIED WITH: USER MANUAL, VINYL! DUST COVER, CLEANING CLOTH AND 01 UNITS FUSES |
