High Temperature Ovens

Product Description

High temperature ovens are required by some applications, where high temperature 300°C to 400°C is required. Laboratory research and light industrial applications are some of areas where high temperature ovens play important role. At ESAW, we have understanding, experience and engineering to design user friendly high temperature oven with temperature ranges up to 300°C, 350°C and 400°C etc following class 3.1 DIN12880 standards. These ovens are suitable for drying, pre-heating, curing, core hardening, aging and component testing etc. There are variety of customization options are available with us at competitive price in India.

Product Information

TECHNICAL SPECIFICATIONS

TEMPERATURE RANGE	50°C to 400°C
TEMPERATURE CONTROLLER	PID temperature controller
THERMOCOUPLE	J Type
HEATER	Sheathed heating element
AIR CIRCULATION	Motor driven blower with V-belt drive
CONSTRUCTION	Double or Triple walled
INNER CHAMBER	Stainless steel
OUTER CABINET	Powder coated GI sheet
INSULATION	High grade ceramic wool
DOOR	Insulated solid door w/ pull action clamp
DOOR GASKET	High temperature gasket
TRAYS	Chrome plated steel trays
EXHAUST	Fume exhaust damper
SAFETY	Over temperature safety controller
POWER SUPPLY	220 Volts 50Hz
ACCESSORIES	External cabinet made of Ss304, GMP model (Inner SS316 & Outer
	Ss304), Timer or profile control, Door safety limit switch, Data
	logging w/ Date, Time & Temperature, Eurotherm temperature
	controller, 7 inch touch screen HMI controller

DIMENSIONS

Model No.	Dimension (in mm)	Capacity	No. of Trays
HTO-28	305 x 305 x 305	28 Ltrs.	2
HTO-45	355 x 355 x 355	45 Ltrs.	2
HTO-95	457 x 457 x 457	95 Ltrs.	2
HTO-125	457 x 457 x 609	125 Ltrs.	3
HTO-225	609 x 609 x 609	225 Ltrs.	3
HTO-340	609 x 609 x 914	340 Ltrs.	4
H TO-450	609 x 609 x 1219	450 Ltrs.	5
HTO-760	914 x 914 x 914	760 Ltrs.	4
HTO-1020	914 x 914 x 1219	1020 Ltrs.	5
