Fully SS Table Top Dental Autoclave

All bodies are made of stainless steel.
The inner and outer chambers and boiler are made of heavy gauge steel with leak-proof argon arc welding. The unit has a spring-loaded safety valve for pressure adjustment and a dead-weight safety valve.
The space between the outer chambers is filled with wool to minimise thermal losses.
hydraulically tested to withstand 2.5 times the working pressure.
The steam boiler is fitted with a water level indicator, pressure gauge, and low water cut-off device.
This affords complete safety to the working personnel against explosive openings.
An automatic vacuum breaker is fitted to all units as a standard accessory in order to break vacuum in case of steam condensation.
The flanged immersion type heating element made from very high-grade material provides fast formation of pressure in the system and is protected through an electric low water cut-off device.
The chamber is fitted with a spring-loaded safety valve and a deadweight release valve.
Sterilisation temperature: 120°C, 135°C.
Suitable to work on 230 volts, single phase, and 50 Hz AC supplies.

TECHNICAL SPECIFICATION
Model No.	10 x 18	12 x 15	12 x 18
Inner Dimension	250 x 450	300 x 375	300 x 450
Capacity	22 Litres	25 Litres	30 Litres
Heater Load	3 KW	3 KW	3 KW
Gasket	Made up of joint less silicon rubber.
Exhaust pressure	manual through the exhaust valve
Sterilizing pressure	1.2 to 1.5 kg/cm2 (15 to 20 psi) at 121°C
Operating pressure	from 15 psi to 20 psi
Pressure gauge	0.2.1 kg/cm2 (30 psi)
