Product Description
Our horizontal autoclave units are made of stainless steel to ensure corrosion resistance surface. Tipple walled construction ensures excellent level of safety. Boiler is fitted separately and connected to the chamber. Water level indicator is also attached to the boiler. Automatic low water cut-off is optional and fitted on demand only. Each unit is fitted with automatic pressure control switch; it is capable to manage pressure between 5 psi to 20 psi with accuracy of ±1 psi. User can easily set the desired temperature with the help of digital controller fitted on the front side of the unit. In order to achieve trustable tight sealing of door, we always use neoprene rubber gasket. In order to make our horizontal autoclave well suited to your application and to make your work easier, we offer a range of optional accessories.
- Stainless steel interior and exterior
- Working pressure 15 psi to 20 psi
- Silicon rubber door gasket
- Automatic pressure control switch
- Powder coated / chrome plated MS Stand
Product Information
| Model No. | CLHA-75 | CLHA-138 | CLHA-185 | CLHA-235 | CLHA-339 | CLHA-552 |
| Dimensions In MM | 400 x 600 | 400 x 1100 | 550 x 750 | 500 x 1200 | 600 x 1200 | 750 x 1200 |
| Volume | 75 Ltrs. | 138 Ltrs. | 185 Ltrs. | 235 Ltrs. | 339 Ltrs. | 552 Ltrs. |
| Construction | Triple Walled | |||||
| Inner chamber | SS 304 with full argon welding | |||||
| External chamber | SS 304 | |||||
| Finishing | Mirror finished inner and external surface | |||||
| Insulation | Glass wool | |||||
| Chamber condensate line | Fitted with steam trap and check valve | |||||
| Working temperature | 121°C | |||||
| Working pressure | 15 to 20 psi | |||||
| Sensor | PT100 | |||||
| Radial locking system | Chrome plated MS | |||||
| Power supply | 440 Volts 50Hz, Three Phase | |||||
| Tray | Perforated tray made of SS 304 | |||||
