Product Description
Polyurethane curing ovens manufactured by us are available from small laboratory grade to large industrial grade sizes. A curing oven is made with insulated closed steel chamber and temperature controlled hot air circulation system. It is designed to improve product quality and durability of material by chemical reaction under speci?c temperature environment. We have complete facility to design, manufacture and install different types of PU Curing Ovens. We have experience to make electrical heated curing oven for Polymers, carbon ?ber, plastic composites, thermoplastics and rubber etc. Each oven is made of thick gauge of steel sheets (Galvanized or stainless steel), thick layer of insulation, heating elements, motor blowers and control panel. There are various safety features we ?t in our PU Curing Ovens to make them safe for material to treat, operator and surrounding environment. With PU Curing Ovens manufactured by ESAW, you can be assured of good product quality at best competitive price in India.
Product Information
TECHNICAL SPECIFICATIONS
| TEMPERATURE RANGE | Up to 3000C |
| CONTROLLER | PID temperature controller |
| CONSTRUCTION | Aluminum painted steel or stainless steel 304 |
| INSULATION | PID temprature controller, Display of SV & PV |
| AIR CIRCULATION | Motor driven blower assembly |
| AIR FLOW DIRECTION | Horizontal & Vertical air flow direction |
| HEATING ELEMENT | Tubular air heating element |
| DOOR | Insulated solid door with spring door latch |
| GASKET | High temperature silicone rubber gasket |
| SAFETY FEATURES | Over load protection, Over temperature protection,Current leakage protection |
| POWER SUPPLY | 220 volts 50Hz or 415 Volts 50Hz |
| ACCESSORIES | Data logging with USB port, Reinforced bottom, Digital timer,Movable trolley |
DIMENSIONS
| Model No. | Dimension(in Inch) | Capacity |
| co-340 | 24″ x 24″ x 36 | 340 Ltrs. |
| co-450 | 24″ x 24″ x 48 | 450 Ltrs. |
| co-750 | 36″ x 36″ x 36 | 760 Ltrs. |
| co-1000 | 36″ X 36″ X 48 | 1018 Ltrs. |
| co-1500 | 40″ x 40″ X 60 | 1570 Ltrs. |
| co-1800 | 48″ x 48″ x 48 | 1810 Ltrs. |
| co-2700 | 48″ x 48″ x 60 | 2715 Ltrs. |
| co-6000 | 72″ x 72″ x 72 | 6115 Ltrs. |
| co-9700 | 84″ x 84″ x 84″ | 9700 Ltrs. |
| co-12600 | 96″ x 96″ x 84″ | 12680 Ltrs. |
