Cooling Incubator

Cooling Incubator

Product Description

ESAW Cooling Incubator are specially designed to conduct life cycle testing, Shelf life studies, general incubation and refrigerated storage. Temperature range adjustable from 5.0 C to 60.0 C with Micro controller based temperature controller. Chambers are exclusively used for seed testing, Biological studies etc.

Foamed in place CFC free PUF insulation ensures temperature stability and reduced power consumption.
Unidirectional air flow system assures even temperature distribution and quick recovery after door openings
Specially designed solid stainless steel wire mesh trays ensure even temperature distribution.
Chamber illumination with fluorescent LED light
U-shaped Stainless Steel Nichrome wire heater
Caster wheels for ease of mobility
High quality PT-100 Sensor for better accuracy

Product Information

Technical Specifications
Cat. No.	ECI –10	ECI –11	ECI –12	ECI –13	ECI –14	ECI –15	ECI –16	ECI –17	ECI –18
Volume	100 Liters	200 Liters	300 Liters	400 Liters	600 Liters	800 Liters	100 Liters	1000 Liters	2000 Liters
Temperature range	5.0 – 60oC
Accuracy	± 0.5oC
Uniformity	± 1.0oC
Control system	Micro control / PLC
No. Doors	Single	Single	Single	Single	Single	Double	Double	Double	Double
No. Of tray	2	3	4	4	4	8	8	8	8
Power	775 W	775 W	775 W	800 W	1150 W	1500 W	2300 W	2300 W	2300 W
Voltage	230 VAC , 50/60Hz
Dimensions (W x D x H) in mm and weight
Internal Dim	435 x 400 x 600	505 x 400 x 1005	565 x 450 x 1205	635 x 530 x 1205	745 x 670 x 1205	1120 x 600 x 1205	1150 x 670 x 1300	1300 x 890 x 1300	1500 x 1030 x 1300
External Dia	580 x 845 x 1275	650 x 880 x 1680	710 x 935 x 1885	780 x 1010 x 1880	890 x 1150 x 1960	1370 x 1075 x 1920	1400 x 1145 x 1920	1550 x 1365 x 1920	1750 x 1505 x 1920
Packing size	707 x 972 x 1478	777 x 1007 x 1883	837 x 1062 x 2088	907 x 1137 x 2083	1017 x 1277 x 2163	1497 x 1202 x 2123	1527 x 1272 x 2123	1677 x 1492 x 2123	1877 x 1632 x 2123
Net Weight	120	145	200	255	280	310	335	360	380
Gross Weight	175	225	275	325	350	400	425	450	480
