Advance Slit Lamp

IPD Range

48.5 – 77mm

Built-in-Filters

Red free, Cobalt blue, Heat absorbing, Neutral density

Movement Ranges:

Longitudinal (in/out)

100mm

Magnification

5 step: 6.5X, 10X, 16X, 25X, 40x

Slit Length/Width

0 – 12mm

Illumination

Halogen 6V-20W

Weight

24kg (packed)

Slit Apertures

0.3, 1, 3, 5, 9, 12mm and continuous 1.5 to 12.0mm

Lateral (left/right)

107mm

Table Base Size

465mm X 316mm

Voltage

100-240V AC

Eyepiece

WF 12.5X/18mm, diopter adj. ± 5mm

Slit Rotation

0 – 180°

Vertical (up/down)

30mm

Microscope

Galilean

Slit Tilt

20°

Frequency

50-60 Hz

Chin Rest Range

80mm

Accessories (Optional)

• Tonometer, Beam splitter, Cameras, Diffuser, Motorized table
